Water Treatment Plants

Are You In Need Of A High Quality Water Purification System? Check Out The DM Plant

Pure water is most essential to live a healthy life but in today’s polluted environment, it has become increasingly difficult. There is a serious need for an advanced purification system, one that is able to remove excess dirt, contaminants from water and bring it out as clean, fresh so that it can be consumed for commercial or industrial purposes. One such system is the Aqua Systems Technology DM Plant, which removes minerals and solid contaminants from the water, making it clean and pure for use.

How Does A DM Plant Operate?

In a DM plant, the purification process is carried out on water such that dissolved solids and minerals are removed and clean water is obtained. Source of water for the system is a water feed, which comes inside the plant and is subject to procedures such as distillation, deionization, electro dialysis and membrane filtration. It also works to prevent scale formation and meal oxidation in the water. It is available in different sizes and materials and you can find units that are either manually operated or completely automated. It can be purchased as a standard else a custom built model for carrying out purifications according to specified needs.

The process by which the Aqua Systems Technology DM plant makes water pure is through demineralization, which involves removing minerals salts present in water through an ion-exchange process. Here is a look at the process occurring inside a DM Plant:

Step 1 - Raw water is sent into the cation resins column

Step 2 - Cation resins column converts the ionized salts in raw water into appropriate mineral acids

Step 3 - Raw water with the mineral acids is sent into Anion Resins Column where it is absorbed

Step 4- De-mineralized (Deionized) water comes out from the Anion Resins Column

When cations Resins become exhausted they are rejuvenated using Hydrochloric acid and likewise occur with Anion resins using caustic Soda (NaOH) solution. Hence resins present in the plant can be used over and over again. The prime means by which the DM plant removes contaminants and minerals from water that is fed into it is through the ion exchange method. However the level of purity of this water is determined by the DM Plant type.

The latest Aqua Systems Technology DM plant is easy-to-operate, user-friendly, uses less power and is robust in quality so it can be used for long periods to do water purification. In the plant’s single body unit is present strongly acidic cation and anion exchange resins, which carry out the demineralization process. This process removes hardness from the water, making it soft.

Use of a DM Plant is most suitable for industries such as pharmaceutical, food, electroplating etc. when there is a need to feed clean water into a boiler system. In the pharmaceuticals and cosmetics DM water is used in the preparation of products to ensure that they have quality and safety. It is used in many inductors for the purpose of sanitizing containers and also equipment.

We are one of the prominent manufacturers of premium-quality DM Plant. DM plant consists of cation and anion beds. Raw water is passed through the cation bed, which converts all ionized salts to the equivalent mineral acids. The anion bed then absorbs these acids to finally give de mineralized and deionized water. When resins are exhausted, the cation resins are re-generated with Hydrochloric acid and the anion resins are regenerated using caustic soda. We supply DM plants to clients at affordable prices.

Features :

. Easy to install
. Easy to maintain
. Affordable

DM plant consists of two Beds (Cation & Anion) Water Quality (Conductivity) from Two Bed Outlet will be between 15 to 20 micro siemens. First raw water is passed through the cation resins column (H+ form), which converts all ionized salts to the equivalent mineral acids. Then Anion Resins Column (OH form), which absorbs these acids and finally gives De mineralized (Deionized) water. When resins are exhausted - the cations Resins are regenerated with Hydrochloric acid (Hcl) and the Anion resins are regenerated by caustic Soda (NaOH) solution. So the same resins can be used over and over again to produce the DM water.
